09 October 2022: Articles
A Rare Case of Giant Cavernous Hemangioma of the Maxillary Sinus
Challenging differential diagnosis, Rare diseaseLucas Alves Teixeira Oliveira12ABCDEF*, Rhayane Patrícia Rodrigues Oliveira1BEF, Laura Cardoso Vasconcelos3BCD, Achilles Alves de Levy Machado4CD, Gustavo Lara Rezende1ABDEG, Fayez Bahmad Jr.2ADG
Am J Case Rep 2022; 23:e937191
BACKGROUND: Hemangiomas are commonly located in the head and neck and rarely in the paranasal sinuses. These are benign vascular lesions, but with an increased risk of bleeding. The surgical approach must have detailed prior planning, given the increased risk of intraoperative bleeding. We herein describe the case of a 32-year-old male patient with recurrent epistaxis, nasal obstruction, and facial deformity due to a giant cavernous hemangioma successfully treated by endoscopic sinus surgery.
CASE REPORT: A 32-year-old man had nasal obstruction and intermittent epistaxis for 2 months. Physical examination also revealed facial deformity with enlargement of the nasal base and bulging in the maxillary region on the right. A soft and friable lesion occupying the entire right nasal cavity without bone erosion was observed on computed tomography (CT scan). Before surgery, the patient underwent angiographic evaluation, with evidence of main irrigation of the lesion by the right maxillary artery, which was then embolized. The patient underwent endoscopic nasal surgery. He maintained postoperative follow-up for 18 months, without recurrence of the lesion. Anatomopathological examination confirmed a cavernous hemangioma.
CONCLUSIONS: Cavernous hemangioma is a benign lesion of the paranasal sinuses. Due to non-specific clinical and radiological findings, its preoperative diagnosis is always challenging. The high index of suspicion of the malignancy should only be discarded after complete anatomopathological evaluation. A correct diagnosis is essential to avoid facial anatomical remodeling while excluding the diagnosis of other malignant lesions.
Keywords: Hemangioma, Hemangioma, Cavernous, Nasal Surgical Procedures
Hemangiomas are benign vascular lesions that are more prevalent in the head and neck regions, which account for 60% of the cases . However, some areas, such as the facial sinuses, are uncommon sites of occurrence . Cases of facial sinus involvement occur more frequently in females and the third decade of life . These lesions typically grow slowly and cause a mass effect on adjacent neurovascular structures, resulting in specific symptomatology . In the central nervous system, cavernous hemangiomas represent 15–25% of vascular malformations and present symptoms of seizures, intracranial hemorrhages, cranial nerve deficits, headache, altered level of consciousness, and fever of unknown origin . The most common symptoms related to paranasal sinuses are nasal obstruction and persistent epistaxis .
The radiological findings may reveal alterations in adjacent bone structures and can cause misdiagnosis with malignant lesions .
A case with similar symptoms was described in a nasal septum hemangioma, also causing obstruction and recurrent epistaxis, but without leading to deformity of the local structures. .
The treatment of cavernous hemangioma, when necessary, is surgical. The nasosinusal endoscopic approach offers the possibility for minimally invasive surgery, with descriptions of procedures to be performed in cases of intercurrence . Performing preoperative vascular studies, such as arteriography and embolization of the lesion, could help better control the bleeding and ensure greater safety in intraoperative management .
We present a case of a 32-year-old male patient with recurrent epistaxis, nasal obstruction, and facial deformity due to a giant cavernous hemangioma, completely removed by a nasal endoscopic approach after arterial embolization, without local recurrence after 18 months of follow-up.
A 32-year-old man who experienced intermittent epistaxis, nasal obstruction, and facial pain for 2 months visited the Emergency Department of a tertiary hospital in Brasilia. Rhinoscopy was performed, and a soft hyperemic lesion was observed with areas of bleeding ulcers that were occupying the entire right nasal fossa and compressing the nasal septum against the left lateral nasal wall. Computed tomography of the facial sinuses showed a mass of soft tissue consistency, with no signs of invasion of the orbital bones and base of the anterior skull (Figure 1).
Preoperative angiography revealed a predominance of tumor vascularization by the right internal maxillary artery, and its embolization was performed 24 h before the surgical procedure (Figure 2). Although the possibility of a malignant lesion was considered, an incisional biopsy was not performed due to the risk of massive incoercible bleeding . Thus, the nasal endoscopic surgical technique was performed under general anesthesia with total excision of the lesion in 4 fragments, without the need for incisions on the facial skin or gums and preserving orbits and the base of the anterior skull.
The postoperative course of the patient was uneventful, without recurrence of the lesion after 18 months of postoperative follow-up.
The anatomopathological examination revealed multiple dilated vessels of various calibers, containing blood and fibrin, limited by a flattened endothelium in the sub-epithelial tissue, stained by hematoxylin and eosin (H & E; ×20), confirming cavernous hemangioma (Figure 3).
Epistaxis and facial deformity are symptoms that should lead to screening for local disease of the paranasal sinuses, as they may be related to benign or malignant diseases, and the size of the lesion is a limiting factor for the type of approach. The type of lesion, whether vascular or not, requires specific preoperative preparation to allow complete resection of the lesion.
Hemangioma is considered a common lesion in the head and neck, and this regional topography is common (60% of cases) . Of the cases that involve the head and neck region, 55% affect the face and only 5% the cervical region , and it is rarely found in the paranasal sinuses . Hemangiomas are more common in women and in the third decade of life in cases of facial sinus involvement .
When these lesions affect the nose and paranasal sinuses, in 80% of the cases the septal region, especially the Kiesselbach’s area, is the most common location, and in 15% of the cases the lateral wall of the nasal cavity is involved . Hemangiomas may be the cavernous or capillary type. The former occurs less frequently, and often originates from the turbinate bone and rarely originates from the maxillary sinus wall . Capillary hemangiomas are found mainly in the vestibule and nasal septum, occasionally associated with pyogenic granuloma lesions. In cases of facial sinus involvement, cavernous hemangiomas are more common .
Although cavernous hemangiomas are benign, the lesion can cause bone destruction and local remodeling in addition to episodes of repeated acute rhinosinusitis due to interference with the natural drainage of the facial sinuses . The differential diagnosis is unilateral lesions of the facial sinuses, such as cysts, mucoceles, papillomas, and malignant neoplasms [12,13].
Hemangiomatous lesions are vascular malformations that can involve the entire body; however, the prevalence in paranasal regions is low . The histology of cavernous hemangioma comprises irregular vessels with thin collagen walls . The vessels vary in size and have a sinusoidal characteristic.
The investigation of unilateral lesions of the nasal fossa ranges from physical examination, nasal endoscopy, and imaging examinations, such as computed tomography, preferably contrast-enhanced, and magnetic resonance imaging (MRI). In cases of vascular lesions, MRI is the examination of choice for delimitation of the lesion and better diagnostic definition. Regarding preoperative preparation, computed tomography is the examination of choice for better definition of surrounding bone structures [16,17].
Cavernous hemangiomas are commonly found as heterogeneous hypodense lesions with little contrast uptake on computed tomography scans. An arteriographic study can also be used as a complement in scheduling the surgical procedure, aiming at cauterization or intraoperative ligature to control bleeding and planning for preoperative embolization [16,17]. In our case, preoperative embolization had a positive effect on the partial regression of the lesion and ease of manipulation due to the low volume of bleeding, which also facilitated postoperative management.
Although common in the head and neck, cavernous hemangioma is uncommon in paranasal sinuses. Due to the tendency of rapid growth and severe episodes of epistaxis, early investigation and management are necessary. In case of vascular injury, the preoperative endovascular approach with embolization, followed by endoscopic resection, can allow complete resection of the lesion, with a lower rate of intraoperative bleeding.
FiguresFigure 1.. Computed tomography (CT) of maxillary sinus hemangioma. Mass of heterogeneous contrast enhancement, occupying the whole right nasal fossa with a widening of the right maxillary sinus opening and bone remodeling of the orbits and ethmoid bone on CT scans of the paranasal sinuses in coronal and axial slices. Figure 2.. Right maxillary hemangioma arteriography. Arteriography demonstrates tumor vascularization with a predominance of the right maxillary artery of the lesion in the coronal position. After embolization of this arterial branch, the sagittal section shows an absence of contrast dissemination to the right maxillary region. Figure 3.. Macroscopic hemangiomatous lesion and histological evaluation. (A) Macroscopic image of a fragment of the paranasal lesion with multi-lobular aspect, friable and with several hemorrhagic spots, measuring 5×4×3 cm. (B) Histological sections reveal fragments of the respiratory mucosa (arrow) exhibiting vascular proliferation with ectatic vessels in exuberant calibers and without endothelial atypia. There are areas of thrombosis, fibrin, and organizing hemorrhage (*).
1.. Müller S, Update from the 4th Edition of the World Health Organization of Head and Neck Tumours: Tumours of the oral cavity and mobile tongue: Head Neck Pathol, 2017; 11(1); 33-40
2.. Pradhan P, Samal S, Preetam C, An unusual case of extensive cavernous hemangioma of the nasopharynx: Iran J Otorhinolaryngol, 2020; 32(108); 53-56
3.. Jayagandhi S, Cheruvu SC, Manimaran V, Mohanty S, Deep neck space infection: Study of 52 cases: Indian J Otolaryngol Head Neck Surg, 2019; 71(Suppl. 1); 923-26
4.. Noblett DA, Chang J, Toussi A, Hemangioma of the cavernous sinus: A case series: J Neurol Surg Rep, 2018; 79(2); e26-30
5.. Fermeli DD, Theofanopoulos A, Papadakos D, Hemorrhage of a cavernous hemangioma of the brainstem presenting with fever of unknown origin: A case report: Am J Case Rep, 2021; 22; e930437
6.. Batsakis JG, Rice DH, The pathology of head and neck tumors: Vasoformative tumors, part 9A: Head Neck Surg, 1981; 3(3); 231-39
7.. Baki A, Nasal septal cavernous hemangioma: J Craniofac Surg, 2018; 29(2); e135-36
8.. Rezende GL, Neto ORM, Kückelhaus SAS, Morbidity in the postoperative follow-up of endoscopic anterior skull base surgery: Braz J Otorhinolaryngol, 2021; 87(6); 689-94
9.. Ghenu IM, Constantin R, Ionescu D, Dragos D, Giant cavernous hemangioma of the liver in a patient with autosomal dominant polycystic kidney disease: Am J Case Rep, 2020; 21; e927188
10.. Hasegawa H, Matsuzaki H, Furusaka T, Maxillary sinus hemangioma: Usefulness of embolization according to classification: Bras J Otolaryngol, 2017; 83(4); 490-93
11.. Marambaia PP, Santos OM, Gomes AM, [Cavernous hemangioma of the maxillary sinus: Case report.]: Arq Int Otorrinolaringol, 2007; 11(4); 485-87 [in Spanish]
12.. Rezende KMPC, Corrêa FNP, Corrêa JPN, [Hemangioma: Description of a clinical case and its importance in the differential diagnosis.]: Rev Assoc Paul Cir Dent, 2016; 70(1); 19-23 [in Spanish]
13.. Araujo RP, Gomes EF, Menezes DB, [Rare sinonasal tumors: Case series and literature review.]: Rev Bras Otorrinolaringol, 2008; 74(2); 307-14 [in Spanish]
14.. Colonetti J, Costa FO, Lima AGDB, Sanchez GB, [Intramedular cavernous hemangioma.]: Arq Neuropsiquiatr, 2003; 61(3B); 864-66 [in Spanish]
15.. Biondi A, Clemenceau S, Dormont D, Intracranial extra-axial cavernous (HEM) angiomas: Tumors or vascular malformations?: J Neuroradiol, 2002; 29(2); 91-104
16.. Fobe JL, Lima JBN, Buone ML, Correa J, [Familial cavernous angioma: Report in three generations.]: Arq Neuropsiquiatr, 1996; 54; 655-60 [in Spanish]
17.. McCormick PC, Michelsen WJ, Post KD, Cavernous malformations of the spinal cord: Neurosurgery, 1988; 23(4); 459-63
