28 November 2022: Articles
Challenging differential diagnosis, Rare coexistence of disease or pathologyAmeen Z. Alherabi 12AEF*, Rehab F. Simsim3A, Suha H. Alsayed1ABE, Ahmad S. Alharthi4BE, Osama Marglani12BCD
Am J Case Rep 2022; 23:e938123
BACKGROUND: Nasopharyngeal carcinoma (NPC) is a rare malignant tumor that arises from the mucosal lining epithelium of the nasopharynx, most commonly at the lateral nasopharyngeal recess or fossa of Rosenmüller. According to global age-standardized incidence rates (ASIRs), in 2018 the incidence rate of nasopharyngeal carcinoma varied from 2.1 to 0.4 per 100 000 in Asia and Europe, respectively. The number of deaths exceeded 50 000. It is one of the few head and neck tumors prone to distant metastasis, most commonly to bones, lung, and liver.
CASE REPORT: In this case report, we present a rare case in which a 23-year-old male patient presented to our head and neck clinic. The patient presented initially to the orthopedic clinic with a right humeral mass lesion 10 cm with history of pain for the last 7 months. A Tru-Cut biopsy confirmed metastatic NPC. A nasopharyngeal biopsy further revealed his lesion to be an NPC undifferentiated type III. The patient was diagnosed with a T3 N2b M1 stage tumor and he was treated with chemoradiotherapy.
CONCLUSIONS: NPCs that present with a shoulder/humoral metastasis are very rare clinically. We are presenting this case to increase the awareness of the Otolaryngology – Head & Neck surgery, Orthopedic, and Oncology community of such a rare presentation.
Keywords: nasopharyngeal carcinoma, Shoulder, Male, Humans, young adult, Adult, Humerus, Biopsy, Nasopharyngeal Neoplasms
Nasopharyngeal cancer (NPC) is a malignancy originating from the mucosa of the nasopharynx commonly at the lateral nasopharyngeal recess or Rosenmüller fossa . NPC highest prevalence is in Southeast Asia, Southern China, the Middle East, and Alaska . According to global age-standardized incidence rates (ASIRs), in 2018 the incidence rate of nasopharyngeal carcinoma varied from 2.1 to 0.4 per 100 000 in Asia and Europe, respectively, and the number of deaths exceed 50000 . It is one of the few head and neck tumors prone to distant metastasis, most commonly to bones, lung, and liver . Males are at 2–3 times higher risk than females , with peak incidence at the fifth decade of life, which might suggest exposure to a carcinogenic agent or Epstein-Barr virus (EBV) in early life .
The epidemiological finding in Saudi Arabia were similar to worldwide data, with peak incidence among people 45–55 years old, with a smaller peak in the 20–24 age group. Most patients present with advanced stage, with a high incidence of non-keratinizing squamous cell carcinoma .
Among all the head and neck cancers diagnosed annually in Saudi Arabia, NPC represent 33%, with an incidence of 0.25 per 10 000 for males and 0.08 per 10 000 for females . NPC has multiple risk factors and associations, which include EBV, salted fish and other foods, tobacco, alcohol, and herbal medicines .
In this case report, we present a rare presentation of shoulder distant metastasis that turned to be of NPC origin, with the aim to increase the awareness of the head & neck, oncology, and orthopedic community of such a rare presentation.
A 23-year-old man was referred to our ENT-Head and Neck clinic from the Orthopedic clinic. He initially presented with a right humeral lesion around 10 cm in size (Figure 1). An X-ray image confirmed a proximal right humeral osseous lesion with a pathological fracture (Figure 2). His shoulder MRI scan showed an aggressive lytic lesion involving the right humerus (Figure 3).
His head and neck examination revealed a nasopharyngeal mass with bilateral palpable cervical lymph nodes. A head and neck CT scan confirmed a large nasopharyngeal mass (Figure 4). A Tru-Cut biopsy demonstrated that the lesion was a malignant metastatic nasopharyngeal carcinoma (NPC) (Figure 5). A nasopharyngeal biopsy further revealed his lesion to be an NPC undifferentiated type III (Figure 6). The case was discussed in the tumor board. The patient was diagnosed with a T3 N2b M1 stage tumor and chemotherapy was planned. The patient was referred to the Oncology Department for treatment. He received chemotherapy with gemcitabine and cisplatin, but he did not compete treatment and was lost to follow-up.
Shoulder and humeral metastases from NPCs are rare. NPCs usually present as neck masses and are typically accompanied by hearing loss, otitis media, nasal obstruction, nasal bleeding, and cranial nerve palsies [6[. Our patient presented with a skeletal concern (a shoulder/humeral lesion), so his initial workup was carried out by an orthopedic surgeon. He was then referred to the otolaryngology division after his biopsy results to focus on his major symptoms, which included nasal obstruction and palpable neck lymph nodes. It is important to keep in mind the uncommon and late presentations of NPC in younger patients.
There is a previous case report  of an NPC that metastasized to the cervical spine presented with right upper-limb weakness, with no history of trauma. On examination she had a mass at the right posterior triangle of the neck. Fiberoptic nasopharyngoscopy examination revealed fullness at the right fossa of Rosenmüller. A biopsy and histopathological examination revealed an undifferentiated non-keratinizing nasopharyngeal carcinoma. A few studies from Saudi Arabia have confirmed this late presentation, including Alherabi  and Zakaria et al  in 77% and 81% of cases, respectively, as stage III and IV presentation in their series [5–8].
We could not identify any published case that reported an NPC that presented with a shoulder metastasis. At time of diagnosis, 5–8% of cases present with distant metastasis; the commonest of which is bony metastasis (70–80%). Survival outcomes in these patients are often poor . NPCs are radio-sensitive tumors; thus, radiotherapy is the mainstay of treatment. With advanced stage NPCs, the standard course is to use radiotherapy with adjuvant chemotherapy. A meta-analysis and many prospective randomized studies have demonstrated that this combination therapy decreases mortality by 18% and an improves the 5-year survival rate by 4–6% [5,8]. Any patient who presents with bony metastasis is considered to be in the advanced stage and palliative care is the main treatment option. It has further been established that younger patients have better response than older patients [6–9]. According to ESMO-EURACAN Clinical Practice Guidelines, palliative chemotherapy should be considered for patients with metastasis of NPC and those have an adequate performance status. The first-line treatment improve overall survival is a combination of cisplatin and gemcitabine, and in patients with newly diagnosed metastatic NPC, locoregional radiotherapy combined with systemic therapy can improve locoregional control and overall survival .
NPCs that present with a shoulder/humoral metastasis are very rare clinically. This report was written to improve the clinical suspicion of the ENT, Otolaryngology, Orthopedic, and Oncology communities to the existence and symptoms of such rare presentations.
One of the major causes of treatment failure and death in nasopharyngeal carcinoma is the propensity of NPC to develop distant metastases , with only 60% of patients completing the planned treatment cycles .
FiguresFigure 1.. Clinical photo of the swollen right shoulder. Figure 2.. A plain chest X-ray image showing soft-tissue swelling of the right shoulder. Figure 3.. Magnetic resonance imaging of the shoulder shows a soft-tissue lesion, which is iso-intense relative to the muscle and shows enhancement in the right humoral head; the lesion extends to the right glenu-humoral head. Figure 4.. A computed topography image with a contrast axial view shows a large RT nasopharyngeal mass extending to the RT pterygoid muscle with erosion in the medial pterygoid process. The lesion further extends to the prevertebral space posteriorly (arrow). Figure 5.. Low-power magnification (3×) of a hematoxylin and eosin stain shows a growing mass under the epithelial lining. Figure 6.. High-power magnification of hematoxylin and eosin stain reveals a sheet of cells with pleomorphism, a high nuclear-to-cytoplasmic ratio, and prominent nucleoli.
1.. Jeyakumar A, Brickman TM, Jeyakumar A, Doerr T, Review of nasopharyngeal carcinoma: Ear Nose Throat J, 2006; 85(3); 168-70 , 172-73, 184
2.. Fu ZT, Guo XL, Zhang SW, [Incidence and mortality of nasopharyngeal carcinoma in China, 2014.]: Zhonghua Zhong Liu Za Zhi, 2018; 40(8); 566-71
3.. Tang LQ, Chen QY, Fan W, Prospective study of tailoring whole-body dual-modality [18F]fluorodeoxyglucose positron emission tomography/computed tomography with plasma Epstein-Barr virus DNA for detecting distant metastasis in endemic nasopharyngeal carcinoma at initial staging [published correction appears in J Clin Oncol. 2016;34(5):519]: J Clin Oncol, 2013; 31(23); 2861-69
4.. Alghamdi IG, Al-Ghamdi GM, The pattern of nasopharyngeal carcinoma in Saudi Arabia: A descriptive epidemiological study of data from Saudi Cancer Registry 2002–2013: International Journal of Advanced Research, 2017; 5(9); 1554-64
5.. Al-Herabi AZ, Head and neck oncology experience in Makkah, Saudi Arabia: Saudi Med J, 2009; 30(10); 1316-22
6.. Zamzuri Z, Mohd Adham SY, Mohamad Saufi A, Nasopharyngeal carcinoma presented with right upper limb weakness: A case report: The International Med J Malaysia, 2012; 11(2); 58-61
7.. Bazarbashi S, Al Eid H, Minguet J, Cancer Incidence in Saudi Arabia: 2012 Data from the Saudi Cancer Registry: Asian Pac J Cancer Prev, 2017; 18(9); 2437-44
8.. Zhang L, Chen QY, Liu H, Emerging treatment options for nasopharyngeal carcinoma: Drug Des Devel Ther, 2013; 7; 37-52
9.. Yang L, Xia L, Wang Y, Development and external validation of nomo-grams to predict the risk of skeletal metastasis at the time of diagnosis and skeletal metastasis-free survival in nasopharyngeal carcinoma: BMC Cancer, 2017; 17(1); 628
10.. Bossi P, Chan AT, Licitra L, Nasopharyngeal carcinoma: ESMOEURACAN Clinical Practice Guidelines for diagnosis, treatment and follow-up: Ann Oncol, 2021; 32(4); 452-65
11.. Lai SZ, Li WF, Chen L, How does intensity-modulated radiotherapy versus conventional two-dimensional radiotherapy influence the treatment results in nasopharyngeal carcinoma patients?: Int J Radiat Oncol Biol Phys, 2011; 80(3); 661-68
12.. Chen L, Hu CS, Chen XZ, Concurrent chemoradiotherapy plus adjuvant chemotherapy versus concurrent chemoradiotherapy alone in patients with locoregionally advanced nasopharyngeal carcinoma: A phase 3 multi-centre randomised controlled trial: Lancet Oncol, 2012; 13(2); 163-71
