14 January 2023: Articles  Italy

Synergistic Sequential Emission of Fractional 1540 nm and 10 600 Lasers for Abdominal Postsurgical Scar Management: A Clinical Case Report

Challenging differential diagnosis, Diagnostic / therapeutic accidents, Rare coexistence of disease or pathology

Federica Fiorentini1ABCD, Irene Fusco ORCID logo2DEF*

DOI: 10.12659/AJCR.938607

Am J Case Rep 2023; 24:e938607

0 Comments

Abstract

BACKGROUND: Abdominal scars can develop following abdominoplasty interventions and can cause severe functional and aesthetic disabilities. Surgery is almost no longer necessary thanks to the accessibility of more recent and sophisticated technology like lasers. Many ablative and non-ablative photothermolysis technologies and equipment have been developed, giving patients and medical professionals more alternatives but also complicating the system to be utilized and the methods to maximize the outcomes. The aim of the current study was to evaluate the volumetric action of 1540 wavelength and the efficacy and safety of the synergic sequential application of a new fractional ablative 10 600 nm CO2 and non-ablative 1540 nm lasers on abdominal postsurgical scar management.

CASE REPORT: We treated a female patient with an abdominal suprapubic scar following abdominoplasty. The patient underwent 3 treatment sessions (with a frequency of 1 session every 50 days) with 1 pass over the entire suprapubic area using 10 600 nm CO₂ fractional laser emission and 1540 fractional laser emission in simultaneous modality. A photographic evaluation was made to monitor the effect of the treatment on the aesthetic appearance of the patient’s suprapubic scar. After 6 months, the photographic assessment showed a significant improvement in scar texture and color. No patient pain or adverse effects were detected.

CONCLUSIONS: This case report describes the possibility of effectively treating abdominal suprapubic scars following abdominoplasty surgery with simultaneous and combined irradiation of 10 600 nm and 1540 nm wavelengths.

Keywords: Abdominoplasty, Abdominal Suprapubic Scar, CO2 Fractional Laser Emission, 1540 Fractional Laser Emission, Synergic Sequential Emissions, Humans, Female, Cicatrix, Treatment Outcome, Carbon Dioxide, Lasers, Gas, Low-Level Light Therapy, Laser Therapy

Background

The number of abdominoplasty surgeries performed has been steadily rising during the past 10 years [1]. Abdominoplasty complications include hematoma, infection, seroma, skin necrosis, hypertrophic scars, neurological symptoms, suture extrusions, umbilical anomalies, pulmonary thromboembolism/deep venous thrombosis, respiratory disorders, and death [2]. Among these, depending on the degree of distortion, abdominal hypertrophic scars have a significant psychological and social impact [3]. Management strategies for abdominoplasty scars include punch grafts, postsurgical scar revision/excision, steroid applications/injections, and laser treatment. However, most of them, particularly surgery management, must be done under local anesthesia and with outpatient procedures resulting in a slow return to work. The availability of more recent and sophisticated technologies, such as lasers, has all but eliminated the need for surgery. With the introduction of more ablative and non-ablative photothermolysis technologies and apparatus, doctors and patients now have more alternatives, but the complexity of the system utilized and the methods to improve the outcomes have also increased [4,5]. By promoting collagen and fibroblasts, fractional ablative CO2 lasers have been demonstrated to be a promising and prospective treatment for enhancing burn scar function/appearance and skin regeneration [6–9]. Moreover, 1540 nm non-ablative fractional lasers can be used to flatten the scar through the delivery of light in an array of narrow, focused micro-beams to create coagulation columns within the skin. This produces an improvement in the skin’s appearance without the risk of inflammation [10–12]. Recent scientific findings demonstrated that the simultaneous combination of the CO2 laser wavelengths of 10 600 nm and 1540 nm non-ablative laser is a valid treatment choice for skin remodeling. In addition, to reduce downtime and pain for patients during treatments, the combination of ablative and non-ablative fractional CO2 lasers produced better skin remodeling results than either laser used alone [13–16]. Based on the existing literature, the purpose of the current study was to assess the volumetric action of the 1540 wavelength, and the efficacy and safety of the synergistic sequential application of a new fractional ablative 10 600 nm CO2 and non-ablative 1540 nm lasers on abdominal postsurgical scar management.

Case Report

Our patient was a 45-year-old woman, in general good health, with a body mass index (BMI) of 22.3 Kg/m2, a Fitzpatrick skin grade of III, and a history of abdominoplasty. Following surgery, the patient had a noticeable extensive suprapubic scar. She did not have any history of keloid formation following prior surgeries.

After 12 months, the scar was not healing, so the patient decided to undergo laser treatment. The following conditions were excluded in the patient: systemic dermatologic conditions (eg, eczema), autoimmune disorders, uncontrolled diabetes, pregnancy, and pigmentary disorders. Informed consent was obtained regarding the risks, advantages, and treatment options. For the abdominal scar removal, the patient underwent 3 treatment sessions with a dual-wavelength system (DuoGlide, DEKA M.e.l.a Srl, Florence, Italy). To work with the fractioned scanning units (μScan DOT), the system creates a multi-technology that includes a 10 600 nm CO2 laser device (60 W) and a 1540 nm diode laser (10 W). A tunable balance between ablation and coagulation depths is possible, with the scanner able to deliver 1 or both wavelengths (1540 nm and 10 600 nm) in sequential emission mode on the same DOT, which is the area that includes both the microscopic ablative zones (MAZs) and microscopic thermal zones (MTZs) in the tissue. This enables the delivery of new and more effective treatments. Utilizing the 1540+CO2 sequence, 1 pass across the whole suprapubic region is made, and both wavelengths simultaneously affect the skin. For the 10600 nm wavelength, power of 16 W, pulse width of 1 millisecond, and stack 2 and 500 µm of spacing were used, whereas for the 1540 wavelength, power of 3 W and pulse width of 5 milliseconds with stack 2 was used. The treatment sessions were performed once every 50 days. The protocol was in conformity with the ethics guidelines of the Helsinki Declaration (1975). A local cream and/or subcutaneous anesthesia were applied before each treatment session. A thermal water-based lotion, cold compression, and sun protection were used for postoperative care (sun exposure avoidance for at least 2 weeks). It is suggested to wait for 1 day before having a shower (hot water avoidance on the treated area until healing is complete). The use of moisturizing and emollient lotions is suggested without any time limitation, which helps to maintain a uniform and compact aspect of the new skin. We monitored for possible adverse effects such as dyschromia, burning sensation, bleeding, and mild to moderate post-treatment erythema, itching, crusting, and edema. Photographic evaluation of the suprapubic scar was performed to monitor the treatment’s effect on aesthetic appearance. Sixty days after the last treatment session, the photographic assessment showed a significant improvement in scar texture and color, as clearly shown in Figure 1. The patient reported no pain or discomfort, and no complications or adverse effects were observed either during treatment or in the follow-up period.

Discussion

STUDY LIMITATIONS:

Our future goal will be to increase the of number cases and make a scale with a significance score range for the evaluation of scars. Further studies involving more patients are needed to confirm the effectiveness of treatment.

Conclusions

This case report describes the possibility of effectively treating abdominal suprapubic scars following abdominoplasty surgery with a simultaneous and combined irradiation of the 2 wavelengths 10 600 nm and 1540 nm.

References:

1.. Matarasso A, Swift RW, Rankin M, Abdominoplasty and abdominal contour surgery: A national plastic surgery survey: Plast Reconstr Surg, 2006; 117; 1797-808

2.. Vidal P, Berner JE, Will PA, Managing complications in abdominoplasty: A literature review: Arch Plast Surg, 2017; 44(5); 457-68

3.. Aarabi S, Longaker MT, Gurtner GC, Hypertrophic scar formation following burns and trauma: New approaches to treatment: PLoS Med, 2007; 4(9); e234

4.. Friedman P, Chapas A, Kilmer S, Optimizing outcomes with the 1550/1927 nm dual wavelength non-ablative fractional laser: Experienced user recommendations: J Drugs Dermatol, 2021; 20(11); 1150-57

5.. Prignano F, Campolmi P, Bonan P: Dermatol. Ther, 2009; 22(Suppl. 1); S8-15

6.. Bonan P, Campolmi P, Cannarozzo G: J Eur Acad Dermatol Venereol, 2012; 26(2); 186-93

7.. Campolmi P, Bonan P, Cannarozzo G: ScientificWorldJournal, 2012; 2012; 546528

8.. Scarcella G, Pieri L, Fusco I, Skin fractional scar treatment with a new carbon dioxide scanner: Histological and clinical evaluation: Photobiomodul Photomed Laser Surg, 2022; 40(6); 424-32

9.. Tenna S, Cassotta G, Brunetti B, Persichetti P, Hyperpigmentated scars of the face following a toxic epidermal necrolysis (TEN): A case report: Dermatol Plast Surg, 2016; 1(2); 1007

10.. Vasily DB, Cerino ME, Ziselman EM, Zeina ST, Non-ablative fractional resurfacing of surgical and post-traumatic scars: J Drugs Dermatol, 2009; 8(11); 998-1005

11.. Gronovich Y, Lotan AM, Treatment of scars with autologous fat grafting and 1540 nm non-ablative erbium laser: J Cosmet Laser Ther, 2022; 24(6–8); 80-83

12.. Haedersdal M, Moreau KER, Beyer DM, Fractional nonablative 1540 nm laser resurfacing for thermal burn scars: A randomized controlled trial: Lasers Surg Med, 2009; 41(3); 189-95

13.. Mezzana P, Valeriani M, Valeriani R, Combined fractional resurfacing (10600 nm/1540 nm): Tridimensional imaging evaluation of a new device for skin rejuvenation: J Cosmet Laser Ther, 2016; 18(7); 397-402

14.. Kislevitz M, Lu KB, Wamsley C, Novel use of non-invasive devices and microbiopsies to assess facial skin rejuvenation following laser treatment: Lasers Surg Med, 2020; 52(9); 822-30

15.. Nisticò SP, Bennardo L, Zingoni T, Synergistic sequential emission of fractional 10.600 and 1540 nm lasers for skin resurfacing: An ex vivo histological evaluation: Medicina (Kaunas), 2022; 58(9); 1308

16.. Magni G, Piccolo D, Bonan P, 1540-nm fractional laser treatment modulates proliferation and neocollagenesis in cultured human dermal fibro-blasts: Front Med (Lausanne), 2022; 9; 1010878

17.. De Angelis F, Kolesnikova L, Renato F, Liguori G, Fractional nonablative 1540-nm laser treatment of striae distensae in Fitzpatrick skin types II to IV: Clinical and histological results: Aesthet Surg J, 2011; 31(4); 411-19

18.. Tenna S, Cogliandro A, Piombino L, Combined use of fractional CO2 laser and radiofrequency waves to treat acne scars: A pilot study on 15 patients: J Cosmet Laser Ther, 2012; 14(4); 166-71

19.. Modena DAO, Miranda ACG, Grecco C, Efficacy, safety, and guidelines of application of the fractional ablative laser erbium YAG 2940 nm and non-ablative laser erbium glass in rejuvenation, skin spots, and acne in different skin phototypes: A systematic review: Lasers Med Sci, 2020; 35(9); 1877-88

20.. Al-Marzouqi H, Nagy E, Sair M, Mabrouk A, The efficacy of low energy fractional carbon dioxide laser therapy in management of postsurgical hyper-trophic scars: The Egyptian Journal of Plastic and Reconstructive Surgery, 2022; 46(3); 231-38

21.. Rabello FB, Souza CD, Farina Júnior JA, Update on hypertrophic scar treatment: Clinics (Sao Paulo), 2014; 69(8); 565-73
